Why is Concurrent Programming hard?

In short, I think, it is hard because on the one hand there is not a single concurrency abstraction that fits all problems, and on the other hand the various different abstractions are rarely designed to be used in combination with each other.

But let us start at the beginning. The terminology might get otherwise in the way. For the purpose of this discussion, I distinguish concurrent programming and parallel programming.

Concurrent programming and its corresponding programming abstractions focus on the correctness of a computation and the consistency of state in the context of parallel or interleaved execution.

Parallel programming and its corresponding programming abstractions focus on structuring an algorithm in a way that parallel computational resources are used efficiently.

Thus, while both programming approaches are related and are often used in combination, their goals and consequently their main abstractions are different. I am not claiming that parallel programming is solved and widely understood, but it is comparably easy to apply it to an isolated problem when performance is an issue. The emphasize here is on isolated, because the integration into an existing system is the hard part and can expose all kind of concurrency issues for which concurrent programming techniques are required as a solution.

When do Concurrency Programming Abstractions Break Down?

The first questions might be why and when are we using concurrent programming? The main reason is the desire to increase “performance”, either by increasing throughput, by reducing latency, or improving interactivity by moving operations off the critical path. Sometimes, a concurrent design also happens to map best on a problem by aligning the program structure with the domain model for instance in terms of tasks or processes and thus is chosen as solution.

A classic example calling for concurrent execution is user interfaces. Independent of a particular solution, the overall goal is to move a computational or I/O task out of the loop that processes user-generated events to maintain the interactivity of an application. This offloading can either be done by using some form of asynchronous I/O and computation library. To give but a few examples, C#’s async/await is frequently used for this purpose, as well as Java’s ExecutorService, or Clojure’s future.

In another simple scenario, the application is already parallel and some form of execution monitoring needs to be added. Either to stear optimizations or even for billing purposes. Depending on the concrete scenario, various solution approaches are available. In a non-performance-critical scenario, a simple atomically modified counter can be sufficient. When performance matters, it might be more appropriate to gather the initial counts local to a single thread, however, this requires later communication to build the sum of all thread-local values, which might lead to consistency issue because it is harder to get one globally consistent snapshot of all local counters. Depending on the requirements all kind of different solutions in-between could be devised. If the count itself for instance does not matter, a scalable non-zero indicator might suffice. Either way, the problem remains the same. An existing parallel program needs to be changed, which potentially introduces concurrency issues.

Keeping something like an independent counter consistent is however rather trivial compared to making parallel or concurrent operations on a large and complex shared data structure yield consistent and correct results. Imagine a tree or graph representation for a program as frequently employed by IDEs. In such a scenario various subsystems might want to change or annotate the graph. For instance to include inferred types, add test coverage, or history information, apply refactorings, or simply account for the change done by the user in the editor. Often the relevant subsystems work concurrently. One could of course the graph immutable and ‘updates’ produce strictly new versions of it. However, for various reasons other choices might be made and then the question arises how consistent updates are possible. Solutions could potentially include locks or software transactional memory (STM).

When making the decision for how to manage the consistency for such a graph that is updated concurrently, the rest of the system has unfortunately to be considered as well. Suddenly our inconspicuous counter might need to take into account that the STM might retry transactions. Similarly, the library for asynchronous tasks might suddenly need to retract a task from the run queue when a transaction is retried. This is the point that makes concurrent programming really hard. Such ‘design’ decision are not strictly local anymore and the question arises not only for STM but for all concurrent programming abstractions: do they compose well?

Huge Number of Different Abstractions

The question of whether concurrent programming abstractions compose is not at all straightforward to answer. As indicated in the discussion in the previous section, there are many different possible requirements in any given situation, so that even the design of a simple counter becomes a complex undertaking. Over the decades, the huge amount of tradeoffs resulted in many different variations of few at least superficially related concepts. The tradeoffs are also not only about performance for instance in terms of how much guarantees a framework may provide. Often somewhat philosophical points come into the discussion. For instance, some people argue that blocking operations preserve better the local sequential view on a system and therefore are simpler to program, often however at the cost of potential deadlocks. On the other hand, a completely asynchronous non-blocking design might be deadlock free, but depending on how the language exposes it, one might end up in callback hell and code becomes hardly maintainable. Yet another aspect might be whether to allow non-determinism or not. It can be easier to reason about a strictly deterministic system. However, such a language or framework might restrict the expressiveness so much that not all conceivable applications can be expressed in it.

To give a few examples, the futures of Clojure and Java are blocking, which always introduces the risk for deadlocks when other blocking abstractions are used in conjunction. The futures offered by AmbientTalk and E (called promises) are inherently non-blocking to fit into the overall nature of these two languages as being non-blocking and deadlock free. Consequently however, both types of futures are used differently and one might argue that one is preferable over the other in certain situations.

Similar is the situation when it comes to the concrete implementation of communicating sequential processes. Personally, I consider the strict isolation between processes, and therefore the enforcement that any form of communication has to go via the explicit channels, as a major property that can simplify reasoning about the concurrent semantics and for instance makes sure that programs are free from low-level data races. However, Go for instance chose to adopt the notion of communicating via channels but its goroutines are not isolated. JCSP, a Java library goes the same way. The occam-pi language on the other hand chose to stick with the notion of fully isolated processes. The same design discussion could be had for implementations of the actor model. AmbientTalk and Erlang go with fully isolated processes, while for instance Akka makes the pragmatic decision that it cannot guarantee isolation because it is running on top of a JVM.

This discussion could go on for quite a while. Wikipedia lists currently more than 60 concurrent programming languages of which most will implement some specific variation of a concept. In previous work, we identified roughly a hundred concepts that are related to concurrent programming.

It can now of course be argued that a single language will not support all of them and thus applications will perhaps only have to cope with a handful concurrent programming abstractions. However, looking at large open source applications such as IDEs, it seems that the various subsystems from time to time start to introduce their own abstractions. NetBeans for instance has various representations of asynchronous task or future like abstractions and there are at least two implementations of somewhat ‘transactional’ systems, one in the refactoring subsystem and another one in the profiling library. They seem to implement something along the lines of STM in different degrees of complexity. And this again raises the question how are these different abstractions interacting with each other. A look at NetBeans bug track yields more than 4000 bugs that contain the word “deadlock” and more than 500 bugs with the phrase “race condition”. While most of these bugs are marked as closed, it is probably a good indication that concurrent programming is hard and error prone.

Concurrent Programming Abstractions Not Designed for use in Combination

Usually concurrent programming is considered hard because low-level abstractions such as threads and locks are used. While NetBeans uses these to a significant extent, it uses also considerably more high-level concepts such as futures, asynchronous tasks, and STM. Now I would argue that it is not necessarily the abstraction level but that various concurrent programming abstractions are used together while they have not been designed for that purpose. While each abstraction in isolation is well tailored for its purpose, and thus reduced the accidental complexity, concurrency often does not remain confined to modules or subsystem and thus the interaction between the abstractions causes significant accidental complexity.

As far as I am aware, the fewest languages have been designed from the ground up with concurrency in mind, and even fewer languages are designed with the interaction of concurrent programming abstractions in mind. While for instance Java was designed with threads in mind and has the synchronized keyword to facilitate thread-based programming, its memory model and the java.util.concurrent libraries were only added in Java 5. Arguable, Java’s libraries are so low-level that languages such as Clojure and Scala try to close the gap. Clojure was consequently designed from the start concurrent programming in mind. It started out with atoms, agents, and STM to satisfy the different use case for concurrency. However, even so Clojure was design with them from the start, they do not interact well. Atoms are considered low-level and do not regard transactions or agents at all. STM on the other hand accounts for agents by deferring message sends until the end of a transaction to make sure that a transaction can be retried safely. With only these three abstractions, Clojure actually could be considered a fine example. However, these abstractions were apparently not sufficient to cover all use cases equally well and futures and promises as well as CSP in form of the core.async library got added. Unfortunately, the abstractions were not designed to integrate well with the existing ones. Instead, there were merely added and interactions can cause for instance unexpected deadlocks or race conditions (for more details see this paper).

In order to give a more academic example, which might not be governed by mostly pragmatic concerns, Haskell might be a reasonable candidate. Unfortunately, even in Haskell the notion of adding instead of integrating seems to be the prevalent one. I am not a Haskell expert, but the STM shows the same symptoms Clojure has, however, in a slightly different way. The standard Control.Concurrent package comes for instance with MVar and Chan as abstractions for mutable state and communication channels. But instead of integrating the STM with these, it introduces its own variants TMVar and TChan. It might be performance reasons that led to this situation. However, from the perspective of engineering large applications this can hardly be ideal, because the question of whether these abstractions can be used without problems in the same application remains unanswered.

Conclusion

I think that concurrent programming is hard because the abstractions we use today are not prepared for the job. They are good for one specific task, but they are not easily used in conjunction with each other. Instead, interactions can lead for instance to unexpected race conditions or deadlocks. And just to support the claim that interaction is an issue, it is not just NetBeans that uses are variety of concurrent programming concepts. Eclipse looks similar, and so do MonoDevelop and SharpDevelop. A study in the Scala world suggests also that application developer chose to combine the actor model with other abstractions for instance for performance reasons.

So, what’s the solution? I think, we need to design languages and libraries that properly integrate a variety of concurrent programming abstractions. How that should look concretely, I don’t know yet. The work of Joeri De Koster shows how solutions could look like for actor languages, and together with Janwillem Swallens, we are extending this work to a wider set of languages. Personally, I still belief that the ownership-based metaobject protocol is a useful foundation to experiment with various different concurrent programming abstractions on top of one language. But, we will see.

For comments, suggestions, ideas, or complains that I did not consider your language that already solves to problem, please catch me on Twitter @smarr or send me a mail.

Domains: Safe Sharing Among Actors

The actor model is a pretty nice abstraction to reason about completely independent entities that interact purely by exchanging messages. However, for software development, some see the pure actor model as too fine-grained and too restrictive exposing many of the low-level issues such as data races again on a higher level again, and thereby forgoing some of its conceptual benefits.

We see the actor model also as a nice way to think about problems. However, we consider them in a more coarse-grained version. For us, actors are not on the level of objects but rather on the level of groups of objects like in the communicating event loop model as proposed by the E language and AmbientTalk. On this level, actors represent larger components, or subsystems if you will, and on multicore systems the question arises how parallelism and resource sharing can be achieved in a safe and efficient manner, without sacrificing the actor model’s (and communicating event loop model’s) nice properties such as freedom of deadlocks and low-level data races.

With the recently published paper below, Joeri took the lead on developing a first idea in the direction of managing shared state in the context of a language based on communicating event loops. The paper is an extension of an earlier workshop paper, and since then, we developed the ideas already further and devised complementary solutions to cover a wider set of uses cases. Still, I think the paper is interesting in its own right, and also defines the semantics of the approach in a formal, and thereby less ambiguous manner.

Abstract

The actor model is a concurrency model that avoids issues such as deadlocks and data races by construction, and thus facilitates concurrent programming. While it has mainly been used for expressing distributed computations, it is equally useful for modeling concurrent computations in a single shared memory machine. In component based software, the actor model lends itself to divide the components naturally over different actors and use message-passing concurrency for the interaction between these components. The tradeoff is that the actor model sacrifices expressiveness and efficiency with respect to parallel access to shared state.

This paper gives an overview of the disadvantages of the actor model when trying to express shared state and then formulates an extension of the actor model to solve these issues. Our solution proposes domains and synchronization views to solve the issues without compromising on the semantic properties of the actor model. Thus, the resulting concurrency model maintains deadlock-freedom and avoids low-level data races.

  • Domains: Safe Sharing Among Actors; Joeri De Koster, Stefan Marr, Theo D’Hondt, Tom Van Cutsem; Science of Computer Programming, 2014, to appear.
  • Paper: PDF
  • BibTex: BibSonomy

Towards Composable Concurrency Abstractions

One of the big questions that came up during my PhD was: ok, now you got your fancy ownership-based metaobject protocol, and you can implement actors, agents, communicating sequential processes, software transactional memory, and many others, but now what? How are you going to use all of these in concert in one application? Finding a satisfying answer is unfortunately far from trivial.

Since I am far from the first person thinking about these problems, we, that is Tom, Joeri, and most notably Janwillem put out heads together to figure out what the main issues are, and what the solutions are others have come up with. Janwillem took the lead and started to write down our first preliminary findings in a paper for the PLACES workshop, co-located with ETAPS in April.

Below, you can find the preprint and abstract of the paper. It is only a first small step, but I hope it won’t be the last one because in the end, the OMOP is only going to be useful if we actually can figure out how to combine the various concurrent programming models it enables in a safe and efficient manner.

Abstract

In the past decades, many different programming models for managing concurrency in applications have been proposed, such as the actor model, Communicating Sequential Processes, and Software Transactional Memory. The ubiquity of multi-core processors has made harnessing concurrency even more important. We observe that modern languages, such as Scala, Clojure, or F#, provide not one, but multiple concurrency models that help developers manage concurrency. Large end-user applications are rarely built using just a single concurrency model. Programmers need to manage a responsive UI, deal with file or network I/O, asynchronous workflows, and shared resources. Different concurrency models facilitate different requirements. This raises the issue of how these concurrency models interact, and whether they are composable. After all, combining different concurrency models may lead to subtle bugs or inconsistencies.

In this paper, we perform an in-depth study of the concurrency abstractions provided by the Clojure language. We study all pairwise combinations of the abstractions, noting which ones compose without issues, and which do not. We make an attempt to abstract from the specifics of Clojure, identifying the general properties of concurrency models that facilitate or hinder composition.

  • Towards Composable Concurrency Abstractions; Janwillem Swalens, Stefan Marr, Joeri De Koster, Tom Van Cutsem; Proceedings of the workshop on Programming Language Approaches to Concurrency and Communication-cEntric Software, 2014, co-located with ETAPS.
  • Paper: PDF
  • BibTex: BibSonomy

Parallel Gesture Recognition with Soft Real-Time Guarantees

More than three years ago, Lode and I started thinking about parallel event processing for realtime systems. The main use case back then was gesture and motion detection based on cameras such as the Kinect. Thierry created the first fully functional prototype called PARTE, and in addition to his master thesis, we wrote a workshop paper about it. Now, we finally got also the revised and extended version of this paper accepted.

Below, you can find preprint and abstract:

Abstract

Using imperative programming to process event streams, such as those generated by multi-touch devices and 3D cameras, has significant engineering drawbacks. Declarative approaches solve common problems but so far, they have not been able to scale on multicore systems while providing guaranteed response times.

We propose PARTE, a parallel scalable complex event processing engine that allows for a declarative definition of event patterns and provides soft real-time guarantees for their recognition. The proposed approach extends the classical Rete algorithm and maps event matching onto a graph of actor nodes. Using a tiered event matching model, PARTE provides upper bounds on the detection latency by relying on a combination of non-blocking message passing between Rete nodes and safe memory management techniques.

The performance evaluation shows the scalability of our approach on up to 64 cores. Moreover, it indicates that PARTE’s design choices lead to more predictable performance compared to a PARTE variant without soft real-time guarantees. Finally, the evaluation indicates further that gesture recognition can benefit from the exposed parallelism with superlinear speedups.

  • Parallel Gesture Recognition with Soft Real-Time Guarantees; Stefan Marr, Thierry Renaux, Lode Hoste, Wolfgang De Meuter; Science of Computer Programming, 2014, to appear.
  • Paper: PDF
  • BibTex: BibSonomy

OMOP Ported to Opal on top of Pharo 3

To prepare some experiments with Pharo’s new compiler infrastructure and a simple AST interpreter, I ported my implementation of the Ownership-based Metaobject Protocol (OMOP) to the Pharo 3. Loading the OMOP into an image will give you an STM implementation, a basic actor system, communicating sequential processes, Clojure-like agents, and active objects. Eventually, the goal is to provide a more extensive set of such concurrent programming mechanisms on top of the OMOP, but for now these five should already give an impression of how the OMOP itself works.

To try it out, it can be loaded into a recent Pharo 3 image with the following code snippet:

Gofer new
	squeaksource3: 'Omni';
	configuration; load.
(Smalltalk classNamed: 'ConfigurationOfOmni') load: #(ST Isolate)
